Sensor & Imaging
- Image Sensor: 2 × 1/2.7″ Image Sensor
- Processor: Ingenic-T23ZN
- Resolution: 4MP (2MP + 2MP)
- Compression Format: H.265
- Lens: 3.6mm + 8mm dual-lens
- Lens Angle: 95° + 48°
- Night Vision: Full-color or Infrared (selectable mode)
- Minimum Illumination: 0.001 Lux
- IR LED Distance: 30 m
- White LED Distance: 20 m
Functions & Detection
- Detection Type: PIR + AI Human Detection
- Detection Distance: 0 – 12 m
- Detection Angle: 110°
- Alarm: Real-time calling or push notification
- Auto Tracking: Supports dual-video linkage and humanoid tracking
- Alarm Lights: Red and Blue Flashing Lights
- Custom Arming Time: Supported
Movement & Control
- Pan Range: 270°
- Tilt Range: 90°
- Rotation Speed: 55°/s (Horizontal), 40°/s (Vertical)
Connectivity
- Network: 4G (Bands depend on region: CN / AS / EU / AU / AM / JP)
- App: UBox (Remote Viewing and Playback)
Audio
- Speaker: Built-in 3W Speaker
- Microphone: Built-in Microphone (Voice Monitoring up to 20 m)
- Two-way Voice Intercom: Supported
Storage & Power
- Local Storage: TF Card (Max 128 GB)
- Cloud Storage: Supported for alarm recording
- Power Supply: Solar Panel + Built-in Batteries (Monocrystalline Silicon)
- Solar Panel Power: 7W
- Battery Capacity: 10400 mAh
- Power Consumption: 4.5W (operating), 0.003W (standby)
Operating Conditions
- Waterproof Rating: IP66 (Indoor/Outdoor Use)
- Operating Temperature: -30°C ~ +60°C
- Humidity: 0% – 90% RH
Additional Information
- Dual 4MP lenses ensure wide-angle and telephoto coverage.
- Supports red and blue flashing lights during alarm events.
- Built-in AI detection reduces false alerts from non-human movements.
